主要技術參數Main Technical Parameters
| 型號規格MODEL | 額定容量Rated Capacity (kVA) | 高壓電壓high voltage(KV) | 低壓電壓 Low voltage(KV) | 頂罩外徑*高H (mm) | 重量W(KG) |
| YDTW-5/50 | 5 | 50 | 0.22/0.38 | Φ320 x 450 | 42 |
| YDTW-50/50 | 50 | 50 | 0.22/0.38 | Φ850x945 | 360 |
| YDTW-10/100 | 10 | 100 | 0.22/0.38 | Φ758 x 982 | 380 |
| YDTW-20/100 | 20 | 100 | 0.22/0.38 | Φ690x900 | 300 |
| YDTW-50/100 | 50 | 100 | 0.22/0.38 | Φ850x1000 | 400 |
| YDTW-100/100 | 100 | 100 | 0.22/0.38 | Φ940x1340 | aoo |
| YDTW-15/150 | 15 | 150 | 0.22/0.38 | Φ1165x1400 | 500 |
| YDTW-75/150 | 75 | 150 | 0.22/0.38 | Φ1120x1400 | 1100 |
| YDTW-150/150 | 150 | 150 | 0.22/0.38 | Φ1350x1570 | 1400 |
| YDTW-20/200 | 20 | 200 | 0.38/0.6 | Φ1166x1B50 | 760 |
| YDTW-100/200 | 100 | 200 | 0.22/0.38 | Φ1450x1950 | 1800 |
| YDTW-200/200 | 200 | 200 | 0.22/0.38 | Φ1800x1950 | 3100 |
| YDTW-25/250 | 26 | 250 | 0.22/0.38 | Φ1250 x 2200 | 1150 |
| YDTW-250/250 | 250 | 250 | 0.38/0.6 | Φ2000x2200 | 3100 |
| YDTW-500/250 | 500 | 250 | 3/6 | Φ2000x2600 | 5800 |
| YDTW-1000/250 | 1000 | 250 | 3/6 | Φ2200 x 2600 | 8200 |
| YDTW-30/300 | 30 | 300 | 0.22/0.38 | Φ1350 x 2300 | 1350 |
| YDTW-150/300 | 150 | 300 | 0.38/0.6 | Φ1450 x 2500 | 2100 |
| YDTW-300/300 | 300 | 300 | 0.38/0.6 | Φ1700 x 2500 | 3700 |
| YDTW-600/300 | 600 | 300 | 0.6/3 | Φ2000 x 2650 | 6100 |
| YDTW-900/300 | 900 | 300 | 3/6 | Φ2000 x 2650 | 7400 |
| YDTW-1200/300 | 1200 | 300 | 3/6/10 | Φ2200x2800 | 8800 |
| YDTW-350/350 | 350 | 350 | O.6/3/6 | Φ2000x2800 | 3600 |
| YDTW-375/375 | 375 | 375 | 0.6/3 | Φ2000X3200 | 4000 |
| YDTW-750/375 | 750 | 375 | 0.6/3/6 | Φ2000 x 3400 | 9600 |
| YDTW-400/400 | 400 | 400 | 0.6/3 | Φ2000 x 3500 | 4100 |
| YDTW-800/400 | 600 | 400 | 3/6 | Φ2200 x 3600 | 10000 |
| YDTW-1200/400 | 1200 | 400 | 3<6 | Φ2600 x 4200 | 12000 |
| YDTW-1600/400 | 1600 | 400 | 3/6/10 | Φ2600 x 4200 | 16000 |
| YDTW-250/500 | 250 | 500 | 0.6/3 | Φ2600 x 4500 | 7800 |
| YDTW-500/500 | 500 | 500 | 0.6/3 | Φ2600 x 4500 | 9800 |
| YDTW-1000/500 | 1000 | 500 | 3/6 | Φ3000 x 4600 | 16000 |
| YDTW-150/500 | 1500 | 500 | 0.6/3 | Φ2600 x 4500 | 6800 |
| YDTW-2000/500 | 2000 | 500 | 3/6/10 | Φ3000 x 4600 | 23000 |
| YDTW-165/550 | 165 | 550 | 0.6/3 | Φ3400 x 5000 | 9100 |
| YDTW-550/550 | 550 | 550 | 3/6/10 | Φ3400 x 5000 | 14000 |
| YDTW-1100/550 | 1100 | 550 | 3/6/10 | Φ3400 x 6100 | 22000 |
| YDTW-2200/550 | 2200 | 550 | 3/6/10 | Φ3400x5100 | 31000 |
| YDTW-300/600 | 300 | 600 | 0.6/3/6 | Φ3400 x 5000 | 7600 |
| YDTW-600/600 | 600 | 600 | 3/6/10 | Φ3400 x 5000 | 16000 |
| YDTW-2400/600 | 2400 | 600 | 3/6/10 | Φ3400x5100 | 26000 |
| YDTW-4800/600 | 4600 | 600 | 6/10 | Φ3400 x 5100 | 36000 |
